Reverse Engineering

Recreate. Refine. Reinvent.

Our reverse engineering services help clients replicate, improve, or redesign existing parts and components — especially when original drawings are unavailable or legacy parts are no longer in production.

What is Reverse Engineering?

We supply precision-engineered tools for die bonding processes, ensuring consistent alignment, stable positioning, and accurate material placement. Our fixtures and supports are built to minimize handling errors and enhance throughput in both manual and automated bonding systems.

Our Reverse Engineering Capabilities

  • 3D Scanning & Dimensional Measurement
  • CAD Reconstruction
  • Material & Tolerance Analysis
  • Design Modification & Optimization

Applications Include

  • Legacy part reproduction (no existing drawing)
  • Competitive product benchmarking
  • Equipment repair and maintenance parts
  • Tooling and jig replacement
  • Design improvements or upgrades

Let's Talk Business!

Contact Us

Type of MachineManufacturerModelQuantityTolerance (mm)
EDMSODICKAD 35L4±0.005
SODICKLMX 322±0.005
ADSPRARK150 F2±0.005
AGIE CHARMILLEFO-231±0.005
WIRE CUTAGIEHSS 1502±0.005
AGIEPROGRESS1±0.005
AGIE100-D1±0.010
AGIECUTE 1000 OIL TECH1±0.002
CHARMILLEROBOFIL 10201±0.002
NEW FUTUREFWC-77451±0.050
SODICKSL600G1±0.002
CNC MILLINGFEELERVPM-30A3±0.010
CHEVALIEREM2040L3±0.010
HARFORDLG-10003±0.010
CNC TURNINGHURCOTMI61±0.005
OKUMAL270E1±0.005
SHENYANGCAK 4085 NI1±0.010
FEELERCHUCK SIZE D301±0.010
GRINDINGOKAMOTO450-C7±0.005
OKAMOTOPFG1±0.005
OKAMOTO52SL1±0.010
EQUIPTOPESG-3A10201±0.010
MITSUIMSG-2501±0.010
CARBIDE GRINDINGCHAVALERACCUGRIND5±0.002
SUPER DRILLOCCANOCT-3525ZA1±0.050
FUTABASD1M1±0.050
MILLINGMANFORDMR-460 TM11±0.050
COMBY-(Laser+Turret Punch)TRUMPHTRUMATIC 10001±0.150
BENDING MACHINE (3200mmX175Ton)ACCURLEUROPRO B321751

This will close in 0 seconds

Type of MachineManufacturerModelQuantityTolerance (mm)
VISION SYSTEMVIEW MASTER–1±0.002
FLEXI VISION–1±0.002
DIGITAL MIRCOSCOPEKEYENCEIM-70001±0.002
CERAMIC BLOCK GAUGETESA–1 SET±0.001
HEIGHT GAUGETESAHITE-6001±0.001
HARDNESS TESTERMITUTOYOHR-4001±0.010
LASER MARKTOYO LASERHZL ISCONIO DBY1N/A
PROFILE PROJECTORSTARRETHDV 3001±0.001
DELTRONICDH 2161±0.001
CMMZEISSSPECTRUM1
CERAMIC BLOCK GAUGETESA–1 SET±0.001
PIN GAUGEINTEC–7 SET±0.001
